Graph Tech Ghost Series Hexpander Interface Wiring Harness (PD-0512-00)
Ensure a rock-solid, noise-free connection between your guitar's internal tone engine and your external MIDI gear with the Graph Tech Ghost Interface Wiring Harness. Specially manufactured by Graph Tech Guitar Labs, this high-grade internal cable is a critical system component for hybrid instruments. It functions as the direct data pipeline that links your onboard Hexpander MIDI Interface board directly to your multi-pin 13-pin female output jack.
Whether you are performing routine maintenance on a heavily gigged guitar, repairing an intermittent synthesizer connection, or constructing a fresh hexaphonic instrument retrofit from the ground up, this premium factory replacement harness guarantees absolute signal integrity. It completely eliminates crosstalk and signal degradation so your synth tracking remains lightning-fast, smooth, and incredibly accurate.
Key Features
Error-Free Keyed Connection: Protect your delicate internal preamp electronics from short circuits and wrong-way insertion. The harness features a 16-hole plug layout engineered with a specialized "keyed" block on both ends. Because one hole is physically blocked at each connector interface, it is physically impossible to plug the harness into your Hexpander board or 13-pin jack backwards.
Optimal 12-Inch Cable Length: Avoid tight stretches and unnecessary internal cable strain. At a generous 12 inches in length, this harness gives builders plenty of slack to execute clean, professional cable loops around tremolo blocks, control pots, and output routings inside standard guitar and bass electronics cavities.
Studio-Grade Signal Integrity: Maintain true, uncompromised digital conversion. Built with premium multi-conductor wiring and molded terminations, this harness shields individual string data channels from ambient electronic interference. It ensures your synth tracks intricate chord voicings and fast runs cleanly without lagging or dropped dynamics.
Solderless Plug-and-Play Simplicity: Skip the complex wiring diagrams. The harness arrives fully assembled out of the box with custom-fitted header plugs that snap securely into place directly onto your hardware pins, ensuring a tight fit that won't vibrate loose under heavy stage use.
Technical Specifications
Brand: Graph Tech Guitar Labs
Product Line: Ghost Modular Pickup System Components
Manufacturer Part Number / SKU: PD-0512-00 (also cross-referenced as 0512-00)
UPC / GTIN: 702725242696 (alternative secondary reference catalog barcode: 702726001551)
Cable Physical Length: 12 inches (approx. 30.48 cm)
Wiring Layout Configuration: 16-Hole Multi-Pin Plug Array
Alignment Safety Profile: 1 Blocked Hole on each interface plug end
Primary Connection Target: Connects Hexpander Board to 13-Pin Output Jack
System Compatibility Note
This wiring harness is an official replacement part engineered for the Graph Tech Ghost Hexpander MIDI Interface System. It is included standard inside the Ghost Hexpander MIDI Basic Kits (PE-0440-00), Advanced Kits (PK-0440-00), and all multi-system combinations like the Acousti-Phonic & Hexpander dual setups.
Luthier Tip: This product includes the internal multi-pin ribbon connector cable only. It does not include the Hexpander preamp circuit board or the external 13-pin jack assembly.
