Description
The industry-standard potentiometer trusted by Fender, Gibson, PRS, and nearly every major American guitar builder for decades. This 500K version is the standard resistance for humbucker-equipped guitars, preserving more top-end brightness than a 250K pot. Now available in both standard right-handed and true left-handed versions — the left-handed pot has its taper reversed internally so it functions correctly, not just repackaged for a lefty build.
Benefits:
- Industry-standard quality trusted by major guitar manufacturers
- 500K resistance keeps humbucker tone bright and open
- True left-handed option available with correctly reversed taper, not a workaround
Features:
- 500K ohm resistance, ±15% tolerance, audio taper
- Split, knurled 1/4" shaft with nut (24 spline)
- Aluminum bushing and shaft
- Includes lock washer and dress washer
Specifications:
- Threaded shaft: 3/8" long, 3/8" diameter
- Overall dimensions: 1-1/4" x 7/8"
- Weight: 16 grams
- Note: Imperial (US) sizing — not compatible with import guitars using metric components
Why Buy From Arkansas Musicworks
We stock genuine CTS potentiometers sourced directly through authorized distribution, backed by our team's own wiring expertise if you have questions.
